Aqua Lung Royal Aqua Master Service Kit #1053-06 - Rectangle

Aqualung Royal Aqua Master "Rectangle Label" version

We are moving inventory to our new sister site www.vintageaqualung.com

Double Hose Regulator Service Kit

*You must know your internal parts, as the early RAM with rectangle label used a different HP seat # 1053-06 (Short penetration pin depth) in combination with pin # 1046-14 (12mm apx.).

It is common in "Rectangle Label" to have these hp seat / pin combinations, however due to divers or vintage service work, all things could be different?

*Note as of 11/01/23 ALL kits come with springs at no extra charge

*Note as of 3/22/24 there is about 1 in 90 divers who report their pin length is not long enough to push the pin pad. This is irregularities or wrong pins, or other that is beyond our control. Custom pin length may be necessary

Royal Aqua Master Kit "Full Version" with springs

• 8630-51 Retainer Ring
• 124628 Filter Ring
• 105106 Filter
• 1000-34 Gasket
• 1046-13 Spring
• 1053-05 Spring
• 1010-06 Spring
• 8210-01 Gasket
• 8210-03 Gasket
• 1000-29 Diaphragm
• 8520-16 Nut
• 1010-07 Disc
• 8201-12 O-Ring
• 1053-06-NS *note correct pin to hp seat depth
• 8340-02 Screw (2)
• 8200-06 O-Ring

*Note this kit contains new style HP seat that has same "Pin Depth" as original 1053-20

*Color of some gaskets may vary depending on what I received from Bryan before he passed away.

*Warning on use of original 1053 hp seat / pin with new style HP seat if you use other style HP Seat such as the current Aqua Lung seat - you will need a longer pin
